Performance characteristics :

1.Hioh-precision, low resistance, to reverse zero clearance and linear low driving force to ensure extended service life.

2. High-precision control and repeatable measurement results ensure a more realistic refection ofthe specimen characteristics,

3. Four-column double-screw double space rigid frame structure.linear travelto ensure the crosshead neutral, thereby reducing test data error, raiseexperimental accuracy.

4. The digital closedloop position control servo motor and gear reducr drive mechanism,the sero motor having a large torque output can be realized in awider load range of high-precision speed control, quick response and full perfommance,

5. The high degree of inteligence system has a self-diagnostic function. t can automaticaly detects over-voltage, over-curent,over-temperature,

6. Automatic hydraulic girip prevents sample slippage. The adjustable gripping pressure prevents damage to the sof material specimen to improve theaccuracy of test results.

7. Optional double cylinder synchronous hydrauic grip, huge clamping force, specimen doesn't sli. The adjustable pressure to prevent damage to the soft

material sample, improving the accuracy of the test results,

8. High-precision tension and compression bi-directional load cel, strong resistance to lateral and impact.

9. There are dozens of different types of fixtures, to meet the different requirements of various industries material testing,

10.Aluminum cover for easy cleaning and a long-lasting-life.

Applications:

Metal wire, strip, bar, tube, sheet,

Rebar. strand.l

Applied Standards.

Load meets or exceeds the following standards: ASTM E4,IS07500-1, EN10002-2, BS1610, DIN 51221.Strain measurement meets or exceeds the following standard: ASTM E83, ISO 9513.BS3846.EN10002-4
