Performance characteristics:

1. High-precision, low resistance, to reverse zero clearance and linear low driving force to ensure extended service life;2. High-precision control and repeatable measurement results ensure a more realistic reflection ofthe specimen characteristics.3. Four-column double-screw double space rigid frame structure,linear travel to ensure the crosshead neutral, thereby reducing test data error,raiseexperimental accuracy.

4. The digital closedloop position control servo motor and gear reducer drive mechanism, the servo motor having a large torque output can be reaized in awider load ranae of hiah-precision speed control., auick response and full perfommance.5. The hioh deoree of inteligence svstem has a selfdiaanosic funcion.lt can automaticaly detects over-votage, over-cuent over-temperature.

6. Automatic hydrauic grip prevents sample slippage. The adjustable grpping pressure prevents damage to the sof materal specimen to improve theaccuracy of test results.7. Optional double cylinder synchronous hydrauic grip, huge clamping force, specimen doesn't slip. The adjustable pressure to prevent damage to the softmaterial sample, improving the accuracy of the test results,

8. High-precision tension and compression bi-directional load cel, strong resistance to lateral and impact,

9. There are dozens of different types of fixtures, to meet the diferent requirements of various industnes material testing.,10,Aluminum cover for easy cleaning and a long-asting-life.

Applications:

Metal wire, strip, bar, tube.l sheet.

Rebar, strand;l

Applied Standards:

Load meets or exceeds the following standards: ASTM E4, IS07500-1, EN10002-2, BS1610, DIN 51221.Strain measurement meets or exceeds the following standard. ASTM E83, IS0 9513. BS3846. EN10002-4
